123
Chapter 12 Data Communication
Using the Cable
The PV Unit comes with a cable for data communication. Use the following
procedure to connect the cable to the PV Unit.
To connect the cable to the PV Unit
1. Turn off PV Unit power.
2. Plug the cable into the cable connector at the bottom of the PV Unit as
shown below.
RE
SET
REP
LAC
E B
ATT
ERIE
S
NO RM
AL O
PER
ATIO
N
To disconnect the cable from the PV Unit
1. Turn off PV Unit power.
2. While pressing the release button indicated by (A) in the illustration
below, disconnect the cable.
RESET
REPLACE BATTERIES
NORMAL OPERATION
(A)
