Cleaning
27
Remove the power supply plug from the outlet.
Lint and dust easily accumulate. Always keep clean.
Retaining ring
Latch lever
yww
Hook
sa.co
Driver
t
Race body
Retaining ring
HOW TO REMOVE THE SHUTTLE HOOK
1. Raise the needle to its highest position.
2. Open the shuttle cover.
3. Take out the bobbin case.
4. Push latch levers outside and remove the retaining ring.
5. Remove the hook by grasping center post of the hook.
NOTE: When needle is lowered, shuttle hook cannot be
removed.
CLEANING SHUTTLE RACE
1. Remove accumulated lint and thread
from the retaining ring, hook, driver and
race body with brush.
2. A cloth dampened with machine oil
should be used to wipe shuttle race
clean.
3. Clean shuttle hook in same manner as
above.
4. Reassemble and push the latch levers
inside.
CLEANING FEED DOG
1. Take out the needle plate.
2. Clean the upper part of feed
dog and shuttle race body
with a brush.
