Triplex Adapter
L1 L2 L1+L2
□ □ [3
LJLT
L1 12
Two Une Phone
□ l 1/L2
u u
Ext Une
External Two Une TAD Fax Machine
You can keep two-line telephones on other wall outlets as always. There are two ways
to add a two-line telephone to the MFC’s wall outlet. You can plug the telephone line
cord from the two-line telephone into the LI -i-L2 jack of the triplex adapter. Or, you
can plug the two-line telephone into the TEL jack of the two-line TAD.
Multi-Line Connections (PBX)___________
Most offices use a central telq)hone system. While it is often relatively simple to
connect the machine to a key system or a PBX (Private Branch Exchange), we
suggest that you contact the company that installed your telephone system and ask
them to connect the MFC for you. It is advisable to have a sqjarate line for the MFC.
You can then leave the MFC in FAX Mode to receive faxes any time of day or night
If the MFC is to be connected to a multi-line system, ask your installer to connect
the unit to the last line on the system. This prevents the unit from being activated
each time a telephone call is received.
As with all fax units, this machine must be connected to a two wire system. If your line
has more than two wires, prc^r connection of the MFC cannot be made.
If you are installing the MFC to work with a PBX:
^ It is not guaranteed that the unit will operate correctly under all circum­
stances with a PBX. Any cases of difficulty should be reported first to the
company that handles your PBX.
^ If all incoming calls will be aaswered by a switchboard operator, it is
recommended that the Answer Mode be set to MANUAL. All incoming calls
should initially be regarded as telephone calls.
^ The unit may be used with either pulse or tone dialing telephone service.
