42
Step 3
With the port adapter halfway out of the slot, disconnect all cables from the port adapter. After disconnecting the
cables, pull the port adapter from its chassis slot.
Step 4
To insert the port adapter, carefully align the port adapter carrier between the upper and the lower edges of the port
adapter slot guide (4) and slide the new port adapter halfway into the port adapter slot (3).
Step 5
Connect all required cables to the port adapter. After connecting all required cables, carefully slide the port adapter all
the way into the slot until the port adapter is seated in the router midplane.
Step 6
After the port adapter is properly seated, lock the port adapter lever (5).
For port adapter documentation, see the
Replace the Port Adapter Jacket Card
Note
Online insertion and removal (OIR) is not supported on the Port Adapter Jacket Card. OIR is supported on the port
adapter.
Figure 25
Removing a Port Adapter
Step 1
Power down the router.
Step 2
Disconnect the router from the power source.
Step 3
Disconnect any port adapter cable.
Step 4
Remove the port adapter by pressing the lock lever until the port adapter releases.
Step 5
Pull the port adapter from the Port Adapter Jacket Card.
1
Port adapter lock lever
2
ETHERNET-10BFL
E
N
R
X
0
1
2
3
4
TX
R
X
TX
R
X
TX
R
X
TX
R
X
TX
0
4
1
3
5
6
FAST SERIAL
EN
TD
TC
RD
RC
LB CD
TD
TC
RD
RC
LB
CD
TD
TC
RD
RC
LB CD
TD
TC
RD
RC
LB CD
TOKEN RING
0
1
2
3
Cisco 7200
Series VXR
ETHERNET 10BT
ENABLED
0
2
1
3
LINK
0
1
2
3
ENABLED
MII
LINK
RJ45
FAST ETHERNET
0
138885
PORT ADAPTER JACKET CARD
EN
AB
LE
D
PW
R
ENCRYPTION/COMPRESSION
SA-VAM2+
1
