6
Operation
The Premier 3-Zone Panel has LEDs and a built-in display to tell the installer and homeowner the current
operating mode of the panel. Refer to Figure 5 and the following descriptions of the panel LEDs for
operation information.
LED Display Panel
Supply Temp
Shows the current air supply temp. Use to set Hi/Lo temp limit.
Hi Temp Press ▲ to display Hi temp cutout setting. Press ▲ to raise or ▼ to lower
Hi temp setting.
Lo Temp Press ▼ to display Lo temp cutout setting. Press ▲ to raise or ▼ to lower
Lo temp setting.
Purge System uses intelligent purge to maximize comfort and energy savings. Press
▼ and ▲ to display purge time. Press ▲ to increase or ▼ to decrease
purge time.
Delay Supply air temperature is outside the Hi/Lo temp cutout. System has turned off
the equipment except the fan.
Callout LED Description
1 Thermostats Shows what calls the thermostats are making to the zone panel. Lights
when thermostat terminal is active.
2 24V Power Lights when the panel is receiving power from the zoning transformer.
3 RH and RC Lights when the HVAC equipment transformer(s) are receiving power.
Available only when C equipment terminal is wired.
4 Equipment Lights when the zone panel is calling to the equipment. Zone panel
controls the equipment LEDs in response to thermostat calls and DIP
switch settings.
5 Emergency Heat Lights when emergency heat is active (cooling is disabled).
6 Damper Lights red when the zone damper is closed, green when the zone
damper is open.
7 Heartbeat Flashes once per second when the panel is normal.
9
