Installer Guide 10
No. Installer Setting
Factory
Setting
Comments
(
Notes follow this table)
Default
Options
(More information follows this table)
13 Fossil Fuel
AE AUX
AE AUX
Select for Electric Auxiliary heat (with compressor)
Backup Heat
[note 4]
AG AUX
Select for Gas Auxiliary heat (without compressor)
14 Compressor Power Outage
oF CPOP
oF CPOP
Disables Power Outage Lockout Delay
Protection
[notes 4, 6]
on CPOP
Enables Power Outage Lockout Delay
15 AC Power Interrupt
AC oF MONR AC oF MONR Disables AC Power Interrupt Warning
Warning
[note 6]
AC on MONR Enables AC Power Interrupt Warning
16 Compressor Short
5 CSCP
5, 4, 3, 2 or Select a compressor short cycle protection delay of 5,
Cycle Protection
0 CSCP
4, 3, 2 or 0 minutes
17 Residual Cooling
60 FAN
90, 60, 30 Select a Residual Cooling Fan Delay of 90, 60,
Fan Delay
or
0 FAN
30 or 0 seconds.
18 Circulating Fan Lock
oF CIRC
oF CIRC
Disables Circulating Fan Lock mode
on CIRC
Enables Circulating Fan Lock mode
19 Adaptive Recovery
oF REC
oF REC
Disables Adaptive (early) Recovery mode
Mode (ARM™)
[note 7]
on REC
Enables Adaptive (early) Recovery mode
20 Indoor Remote Sensor
I SENS
I SENS
Temperature is sensed from thermostat only.
Control*
[note 8]
E SENS
Temperature is sensed from remote sensor(s) only.
(wireless sensors must
(averaged if more than one)
be paired)
A SENS
Temperature is averaged with the thermostat and
the remote sensor(s).
21 Lockout Security Level
2 LOCK
2 LOCK
If locked – Complete lockout is enabled
(set 3-digit code in
1 LOCK
If locked – Partial lockout is enabled (SpeedBar
®
is
user settings)
still functional)
22 Auto Changeover
3 BAND
2, 3, 4 or 5 Select a Dead Band of 2°, 3°, 4° or 5˚ F
Dead Band
[note 10]
BAND
(1°, 2° or 3° C) for Auto Changeover mode.
23 Compressor Balance
NO BALC
NO BALC
Disables Balance Points
Point
[notes 4, 10]
0-50 BALC Select a Compressor Balance Point of 0° - 50°F
(-18° - 10° C)
24 Auxiliary Heat Balance
NO BALA
NO BALA
Disables Balance Points
Point
[notes 4, 10]
70-40 BALA Select a Auxiliary Heat Balance Point of 70°- 40° F
(21°- 4° C)
25 Economizer Fresh Air or
OA NONE
OA NONE
Disables Fresh Air Intake option
Output Control
[note 11]
OA ECON
Enables Fresh Air Intake (Economizer Mode)
OA TOD
Enables Fresh Air Intake (Time of Day Mode)
26 Heat Set Point Upper Limit
90LIM
90-60 LIM Select a Heat Set Point Upper Limit of 90°-60° F (32°-10° C)
27 Cool Set Point Lower Limit
45LIM
45-80 LIM Select a Cool Set Point Lower Limit of 45°-80° F (7°-27° C)
28 Humidification
OFF
OFF
Disables Humidification
[note 12]
DEP
Enables Dependant Humidification
IND
Enables Independent Humidification
29 Auto Humidity Set
AUTO
AUTO
Enables automatic humidity control based on
Point Limit
[notes 10, 12]
outdoor temperature.
MAN
Enables manual humidity control from thermostat.
30 Dehumidification
OFF
OFF
Disables Dehumidification
[note 12]
NI
Normally inactive (open) relay
NA
Normally active (closed) relay
31 Installer Clear
CLR0
CLR0
Clear Off - No changes made to settings
CLR1
Clears wireless remote sensor settings
CLR2
Clears all thermostat settings (factory defaults)
Options (shaded) 28 - 30 only appear if optional wireless remote humidity sensor is installed.
*When an outdoor sensor is connected, the thermostat automatically recognizes it. Press room temperature digits to
display outdoor temperature.
NOTE: Additional options such as Service Monitors, Setting the lock code, audible tone, etc. are
located in the User Settings – See User manual for information on setting these options.
