S E AM L E SS HDBAS E T M AT RIX S W IT CHE R – HX - 2 344Z
52
3. Adjust the switcher on the Extender to REMOTE mode for upgrading the HX-SRPUW
F/W.
REMOTE (HX-SRPUW Extender) Firmware Upgrade
Pin 1 Pin 2
REMOTE ON OFF
4. Enable the HX-2344Z power.
5. On the control PC, process the UpdateRX_13090-C.bat file to upgrade Extender
firmware. (The update file name is only for reference, it will be different based on
version.)
