S E AM L E SS HDBAS E T M AT RIX S W IT CHE R – HX - 2 344Z
11
Resolution: The HX-2344Z Switcher supports you VGA, 480P, SVGA, XGA, 720P,
SXGA, UXGA and 1080P output resolutions. It can convert the input source resolution
to correspond the output resolution.
ALL: This key allows you to set single input channel to all output channels. The usage
of “ALL” key is the same as the output key.
- Press the “ALL” key.
- Select the one of the IN 1~4 keys.
- The selected IN x key will route the input signal to all output channels.
- You can also press the “ALL” key and then press the “OFF” key to disable all
the displayed routing settings.
OFF: Disable the entire output channels. Press one of the OUT x keys that want to be
disabled for the output channel, then press the “OFF” key. Likewise, press the “ALL”
key and then press the “OFF” key to disable all the displayed routing settings. In
addition to routing port menu, press “OFF” key can return to the main screen during
implementing in other menu. You can also press “OFF” key to disable the light of LCD
screen for saving power.
IR: Infrared receiver can receive signals from the Matrix Switcher Remote Controller
EDID: FIX (fix mode) and OUT1 (access the first output channel) selection key.
- FIX mode: The HX-2344Z will supply a set of fixed EDID values to support up to
only 1080P high performance TV.
- OUT1 mode: The HX-2344Z will access the EDID values of high performance TV
that connected to the first output channel, and copy the EDID value to all the input
channels so that the DVD player can support to all the HDTV.
RETURN: Press this key to go back main screen.
PLUG: Press this key to show you the status of all connected input/output jacks on the
rear panel. If the jack is in HPD (hot plug detect), it will appear “O” on the screen.
Alternatively, it will appear “X” specified the jack is unused.
INFO: Press this key to show you the device’s version, ID and IP address.
Press PLUG+INFO keys simultaneously to show you the firmware versions of
modules.
STO: The “Store Key” saves all current output/input corresponding relations up to 4
sets for a memory control.
- Press the “STO” key firstly.
- Arrange memory location. (Support up to 4 sets of memories, you can select the
memory location through OUT1~OUT4/IN1~IN4.)
