S E AM L E SS HDBAS E T M AT RIX S W IT CHE R – HX - 2 344Z
27
Figure 6-17 Aspect Ratio for Full Screen
B. DIP Switcher Pin 2: IR mapping configurations
ON: IR mapping (remote => local) by channel route, remote user can control the
selected local DVD player by IR.
OFF: IR mapping (local and remote) fixed.
Right DIP Switcher:
A. DIP Switcher Pin 1 to 5: Switch to down (ON) is specified for “0”, on the other hand
to up (OFF) is specified for “1”. For Device ID settings refer to 6.7.7 Device ID Settings
錯誤! 找不到參照來源。.
B. DIP Switcher Pin 6: Mater/Slave Enable/Disable. Only one Matrix Switcher can be
connected to other device and control PC via RS-232/LAN that is specified as Master,
others are specified as Slave.
ON: RS-485 Serial Master and RS-232 / LAN Enable.
OFF: RS-485 Serial Slave and RS-232 / LAN Disable.
C. DIP Switcher Pin 7: Switch between RS-232 port and LAN port connection.
ON: RS-232
OFF: LAN
D. DIP Switcher Pin 8: Reset the web server IP address to 192.168.0.3
The steps are as below:
1. Please adjust the Pin8 to ON and re-start the Matrix Switcher.
2. After the Matrix Switcher re-starts about 10 seconds, shut down it.
3. For a normal operation, please adjust the Pin8 to OFF, then power on the Matrix
Switcher again. The IP address will be restored to the default value: 192.168.0.3
6.7.6 DIP Switcher for 2 Pins
Figure 6-18 DIP Switcher for HD-BaseT Setting
A. Pin 1: Local F/W upgrade.
B. Pin 2: Remote F/W upgrade.
C. Pin 3: Normal.
