S E AM L E SS HDBAS E T M AT RIX S W IT CHE R – HX - 2 344Z
48
Specifications
Hardware
HDMI OUT HDMI A-Type Female x 1
LINK RJ-45 Connector x 1
IR OUT 3.5ψ Stereo Jack x 1
IR IN 3.5ψ Stereo Jack x 1
2 Pins Dip Switcher F/W Upgrade Setting
RS-232 Connector DB9 Female x 1 that can used to F/W Upgrade
LED indicators MODE/LINK/HDCP/POWER
Power Supply From Link Ethernet Cable
Housing Metal
Weight HX-SRPUW: 328g
Dimensions (LxWxH) 150x75x33mm
Multimedia
Max. Resolution 4K x 2K@30Hz, 8-bit
Highest TMDS Frequency 300MHz
Control Information
HDMI Cable Distance 10 meters (At least)
Cat.5e Cable Distance 70 meter (Max.)
Remote Control IR Receiver, IR Blaster
