Attention!
In the following please fi nd the
instructions for the safe use of the
instrument.
Please use only the original
accessories for the instrument. Please
refer to the ordering guide and the
technical data.
Please do not expose the instrument
for a long time to highly humid
environment and avoid the forming of
condense water (see technical data).
Save the instrument from water
splashes and chemicals.
Do not carry out any mechanical or
electrical repair work at the instrument
yourself. In case of need please
contact our technical service.
Sample!
For testing purposes insert the sample
into the eccentric clamping ring and fi x
it tightly (max. 40 Nm).
In case you use test panels beware of
sharp edges. Only the test panels as
described in the technical data shall
be used.
RS-232 interface!
Only instruments shall be connected
to the RS-232 interface which comply
with the requirements for safety extra
low voltage. The 5.1 VDC exit
provides the connection for the
microscope only.
