Chapter 3
Benchmark 2.0LN Low NOx Boiler
GF-123
Operation Installation, Operation and Maintenance Manual OMM-0046_0F
Page 40 of 172 AERCO International Inc.● 100 Oritani Dr. ● Blauvelt, NY 10913. ● Ph: 800-526-0288 PR1 10/17/12
3.6 CONFIGURATION MENU
The Configuration Menu shown in Table 3-4 permits adjustment of the Internal Setpoint (Setpt)
temperature regardless of whether the valid password has been entered. Setpt is required for
operation in the Constant Setpoint mode. The remaining options in this menu require the valid
password to be entered, prior to changing existing entries. This menu contains a number of
other configuration settings which may or may not be displayed, depending on the current
operating mode setting.
NOTE
The Configuration Menu settings shown in Table 3-4 are Factory-Set in
accordance with the requirements specified for each individual order.
Therefore, under normal operating conditions, no changes will be required.
Table 3-4. Configuration Menu
Available Choices or Limits
Menu Item Display Minimum Maximum Default
Internal Setpt Lo Temp
Limit Hi Temp Limit 130°F
Unit Type KC Boiler, KC Boiler LN,
BMK Boiler Std, BMK Boiler
LN, BMK Boiler Dual,
KC Water Heater, KC Wtr
Heater LN, Innovation WH
BMK Boiler
LN
Unit Size
(See NOTE at end
of Table 3-4) 750 MBH, 1000 MBH, 1500
MBH, 2000 MBH, 3000 MBH
2000 MBH
(2.0 MBTU)
Fuel Type Natural Gas, Propane Natural Gas
Boiler Mode Constant Setpoint,
Remote Setpoint,
Direct Drive
Combination
Outdoor Reset
Constant
Setpoint
Remote Signal
(If Mode = Remote
Setpoint, Direct
Drive or
Combination) 4 – 20 mA/1 – 5V
0 -20 mA/0 – 5V
PWM Input (BMS)
Network
4 – 20 mA,
1-5V
Bldg Ref Temp
(If Mode = Outdoor
Reset) 40°F 230°F 70°F
Reset Ratio
(If Mode = Outdoor
Reset) 0.1 9.9 1.2
Outdoor Sensor Enabled or Disabled Disabled
System Start Tmp
(If Outdoor Sensor
= Enabled) 30°F 100°F 60°F
