66 SNMP Management ELS100-24TX
Cabletron Proprietary MIB Extensions
Areas of ELS100-24TX switch functionality not covered by the standard
RFC MIBs are specified in the Cabletron private MIB. This MIB definition
is specified separately from MIB-II. Areas covered in this MIB include
various system, switch, and port level information. System information
MIB variables are shown in Table 5-1, switch information variables in
Table 5-2, and port variables in Table 5-3.
Table 5-1. System Information Variables
Variable Description
SerialNo Serial number of the unit.
TftpIpAddress TFTP server IP address for TFTP downloads.
TftpFilename Filename of the download upgrade file on the
TFTP server.
PowerUpCount Cumulative number of times switch has powered
up or been reset.
BroadcastCutoffRate Per second rate past which broadcast and
destination unknown unicast frames are not
flooded on each group of 8 ports on the switch.
GatewayIPAddress IP address of the default gateway (router) to which
packets destined for another subnet are sent.
TftpStartDownload Start TFTP downloads via SNMP, using
TftpIpAddress and TftpFilename.
BootpDhcpEnable Enable/disable BootP/DHCP for IP address
configuration.
Reset Remotely execute a software reset of the switch.
