36 ELS100-24TX User Interface ELS100-24TX
VLAN Menu
The VLAN Menu displays the configuration of VLANs in the switch and
allows access to the VLAN #n Configuration Menu to create and configure
VLANs. Select b from the VLAN Configuration Menu to view the VLAN
Menu. Figure 3-12 shows the VLAN Menu and the accompanying table
describes the VLAN Menu.
Figure 3-12. VLAN Menu
VLAN MENU Access Control: READ/WRITE
ID VLAN NAME PORTS IN VLAN VLAN EGRESS PORTS
-------------------------------------------------------------------------------------------------------
1 default
1-24 None
c. Configure d. Delete x. Previous Menu
Enter Selection:
Field Description
ID The identification number of the VLAN (1-4 character
range).
VLAN Name The administrative name assigned to the VLAN (1-14
character range; entering a VLAN name is not required).
Ports in VLAN The ports assigned to the VLAN.
VLAN Egress Ports The egress (exit) ports which link the ELS100-24TX to
other devices which also include members of the same
VLAN.
Selection Description
Configure Allows you to configure an existing VLAN listed in the
VLAN table, create a new VLAN (1-4094 numerical
range), and to open the VLAN #n Configuration Menu.
Delete Allows you to delete a specific VLAN.
