9032579-03 ELS100-24TX User Interface 39
Class of Service Configuration Menu
The Class of Service Configuration Menu allows you to configure Class of
Service settings for the system as well as to set the Class of Service for
VLAN tagged frames. Select d from the Switch Configuration Menu to
view the Class of Service Configuration Menu. Figure 3-15 shows the
Class of Service Configuration Menu and the accompanying table
describes the Class of Service Configuration Menu.
Figure 3-15. Class of Service Configuration Menu
CLASS OF SERVICE CONFIGURATION Access Control: READ/WRITE
a. Class of Service Enable No
b. Priority Threshold 4
c. Configure Port Priority
x. Previous Menu
Enter Selection:
Selection Description
Class of Service Enable Allows you to enable (Yes) or disable (No) Class of
Service operation for the system.
Priority Threshold Allows you to enter the global priority threshold level.
The configurable range is 0-7 (0=low, 7=high).
VLAN tagged frames with a priority level below this
threshold level will be assigned normal priority level
through the switch.
VLAN tagged frames with a priority level equal to or
greater than this threshold level will be assigned high
priority through the switch.
Configure Port Priority Allows you to open the Port Priority Menu for config-
uring Class of Service information per port.
