9032579-03 ELS100-24TX User Interface 27
SNMP Configuration Menu
The SNMP Configuration Menu allows you to modify SNMP-related
configuration parameters. Select a from the System Configuration Menu
to view the SNMP Configuration Menu. Figure 3-5 shows the SNMP
Configuration Menu and accompanying table describes the SNMP
Configuration Menu.
Figure 3-5. SNMP Configuration Menu
SNMP CONFIGURATION Access Control: READ/WRITE
a. SNMP Private Community Name private
b. SNMP Public Community Name public
c. Trap Destination #1 000.000.000.000
d. Community Name #1 public
e. Trap Destination #2 000.000.000.000
f. Community Name #2 public
g. Trap Destination #3 000.000.000.000
h. Community Name #3 public
i. Trap Destination #4 000.000.000.000
j. Community Name #4 public
x. Previous Menu
Enter Selection:
Selection Description
SNMP Private
Community Name The community name for read/write SNMP access to the
device (1-10 character range; the default name is: “pri-
vate”).
SNMP Public
Community Name The community name for read only SNMP access to the de-
vice (1-10 character range; the default name is: “public”).
Trap Destination #1 The IP address of trap destination #1 where SNMP trap
messages are forwarded.
Community Name #1 The SNMP community name to use for traps forwarded to
trap destination #1.
Trap Destination #2 The IP address of trap destination #2 where SNMP trap
messages are forwarded.
Community Name #2 The SNMP community name to use for traps forwarded to
trap destination #2.
Trap Destination #3 The IP address of trap destination #3 where SNMP trap
messages are forwarded.
Community Name #3 The SNMP community name to use for traps forwarded to
trap destination #3.
Trap Destination #4 The IP address of trap destination #4 where SNMP trap
messages are forwarded.
Community Name #4 The SNMP community name to use for traps forwarded to
trap destination #4.
