9032579-03 ELS100-24TX User Interface 35
VLAN Configuration Menu
The VLAN Configuration Menu allows you to configure the operation of
virtual LANs (VLANs) in the switch. Select c from the Switch Configuration
Menu to view the VLAN Configuration Menu. Figure 3-11 shows the VLAN
Configuration Menu and the accompanying table describes the VLAN
Configuration Menu. See Appendix D, “Virtual LANs (VLANs)” for more
information about this feature.
Figure 3-11. VLAN Configuration Menu
VLAN CONFIGURATION Access Control: READ/WRITE
a. VLAN Enable No
b. VLAN Menu
c. VLAN Port Menu
x. Previous Menu
Enter Selection:
Selection Description
VLAN Enable Allows you to enable (Yes) or disable (No) the
global VLAN operation of the switch.
VLAN Menu Allows you to open the VLAN Menu.
VLAN Port Menu Menu for configuring VLAN information per
port.
