KEYENCE N-UB - Manual

1 E N-UB-IM
Dedicated Communication Unit
USB Output Type
N-UB
Instruction Manual
■ General precautions
• At startup and during operation, be sure to check that the
functions and performance of the N-UB is operating properly.
• We recommend that you take substantial safety measures to
avoid any damage in the event a problem occurs.
• If the N-UB is modified or used in any way other than described in
the specifications, its function and performance cannot be
guaranteed.
• When the N-UB is used in combination with other instruments, the
function and performance may be effected by operating conditions
and the surrounding environment.
• Do not use the N-UB for the purpose of protecting the human
body.
• The information contained in this manual is subject to change
without notice.
■ Notice
When this product is used under the circumstances and operating
environments described below, adhere to the limitations of the ratings,
take adequate measures to ensure safety such as fail-safe installations
and consult a KEYENCE sales representative.
• For use under circumstances or environments which are not
described in the manual
• For use with nuclear power control, railway, aircraft, vehicles,
incinerators, medical equipment, entertainment equipment, safety
devices etc.
• For use in applications where death or serious property damage is
possible and extensive safety precautions are required.
■ For properly using the product
Do not install the N-UB in the following locations:
• Locations subject to direct sunlight
• Locations where the surrounding air temperature is outside the
range of 0
to +50 °C or locations subject to condensation as the
result of severe changes in temperature
• Locations where the ambient humidity is outside the range of 35
to 85%RH.
• Locations subject to corrosive or flammable gases
• Locations subject to dust, salts, iron dust, or oil smoke
• Locations subject to shock or vibration
• Locations subject to exposure of water, oil, or chemicals
• Locations where strong magnetic or electric fields are generated
■ UL certification
The N-UB complies with the following UL/CSA standards and has
obtained the UL/C-UL certification.
• Applicable standard UL508, UL60950-1
• UL File No. E207185, E167973
• UL category NRAQ/NRAQ7, NWGQ2/NWGQ8
Be sure to observe the following installation and environment conditions.
• Pollution degree 2
• Overvoltage category I
Caution - Do not connect directly to the branch circuit. This product must
be supplied power by a suitable, approved isolated transformer or power
supply not exceeding 200 VA max.
Attention - Ne raccordez pas l'unité directement au circuit de dérivation.
Ce produit doit être alimenté par un transformateur adapté, isolé et
approuvé ou une alimentation ne dépassant pas 200 VA.
■ FCC regulations
The N-UB complies with the following FCC EMI regulations.
• FCC Part 15 Subpart B, Class B digital device
■ Canada IC (Industry Canada) regulations
The N-UB complies with the following IC EMI regulations.
• ICES-003, Class B digital apparatus
■ CE marking
The N-UB complies with the following essential requirements of the EU
Directive.
• EMC Directive (2004/108/EC)
The following harmonized standards are applied to this product in order
to confirm the compliance.
• Applicable standards (EMI) EN55011, Class A
EN55022, Class B
• Applicable standards (EMS) EN61000-6-2
EN61000-6-1
* The length of the communication and power cables should be
less than 30 m.
* To make the N-UP conform to the CE marking, attach the
ferrite core to the USB cable as shown in the following
diagram.
Recommended types
Model: ZCAT2035-0930 (TDK)
OP-31973 (Keyence)
DANGER
Failure to follow these instructions may lead to death or
serious injury.
WARNING Failure to follow these instructions may lead to injury.
CAUTION
Failure to follow these instructions may lead to product
damage (product malfunction, etc.).
Note Provides additional information on proper operation.
TIPS
Indicates useful information or information that aids
understanding of text descriptions.
For Safely Using the Product
CAUTION
• Do not use the N-UB in an environment subject to
flammable, explosive, or corrosive gases.
• Be sure that all screws are tightened securely.
• Use crimp contacts of the specified size for wiring.
• The N-UB uses a 24 VDC power supply. Using a power
supply outside this range or an AC power supply may
cause product failure.
• Do not disassemble or modify the N-UB.This may cause
product failure.
• Locate the cables as far as possible from high-voltage
lines and power lines. Otherwise, generated noise may
cause product failure or malfunctions.
• The N-UB is a precision instrument. If the unit is
dropped or shock is applied, it may be damaged. Use
caution when unpacking, carrying, and mounting.
• Be sure to observe all warnings, cautions, and
precautions specified in the manual.
96M13453
Foreign Regulations and Standards
Package Contents List
Main unit Instruction manual
1 E N-UB-IM
Dedicated Communication Unit
USB Output Type
N-UB
Instruction Manual
■ General precautions
• At startup and during operation, be sure to check that the
functions and performance of the N-UB is operating properly. • We recommend that you take substantial safety measures to
avoid any damage in the event a problem occurs. • If the N-UB is modified or used in any way other than described in
the specifications, its function and performance cannot be
guaranteed.
• When the N-UB is used in combination with other instruments, the
function and performance may be effected by operating conditions
and the surrounding environment.
• Do not use the N-UB for the purpose of protecting the human
body.
• The information contained in this manual is subject to change
without notice.
■ Notice
When this product is used under the circumstances and operating
environments described below, adhere to the limitations of the ratings,
take adequate measures to ensure safety such as fail-safe installations
and consult a KEYENCE sales representative.
•
For use under circumstances or environments which are not
described in the manual
• For use with nuclear power control, railway, aircraft, vehicles,
incinerators, medical equipment, entertainment equipment, safety
devices etc.
• For use in applications where death or serious property damage is
possible and extensive safety precautions are required.
■ For properly using the product
Do not install the N-UB in the following locations:
• Locations subject to direct sunlight • Locations where the surrounding air temperature is outside the
range of 0 to +50 qC or locations subject to condensation as the result of severe changes in temperature • Locations where the ambient humidity is outside the range of 35
to 85%RH.
• Locations subject to corrosive or flammable gases • Locations subject to dust, salts, iron dust, or oil smoke • Locations subject to shock or vibration • Locations subject to exposure of water, oil, or chemicals • Locations where strong magnetic or electric fields are generated
■ UL certification
The N-UB complies with the following UL/CSA standards and has
obtained the UL/C-UL certification.
•
Applicable standard UL508, UL60950-1 • UL File No. E207185, E167973 • UL category NRAQ/NRAQ7, NWGQ2/NWGQ8 Be sure to observe the following installation and environment conditions.
• Pollution degree 2 • Overvoltage category I Caution - Do not connect directly to the branch circuit. This product must
be supplied power by a suitable, approved isolated transformer or power
supply not exceeding 200 VA max.
■ FCC regulations
The N-UB complies with the following FCC EMI regulations.
•
FCC Part 15 Subpart B, Class B digital device ■ Canada IC (Industry Canada) regulations
The N-UB complies with the following IC EMI regulations.
•
ICES-003, Class B digital apparatus ■ CE marking
The N-UB complies with the following essential requirements of the EU
Directive.
•
EMC Directive (2004/108/EC)
The following harmonized standards are applied to this product in order
to confirm the compliance.
• Applicable standards (EMI) EN55011, Class A
EN55022, Class B • Applicable standards (EMS) EN61000-6-2 EN61000-6-1 * The length of the communication and power cables should be
less than 30 m. * To make the N-UP conform to the CE marking, attach the
ferrite core to the USB cable as shown in the following
diagram.
Recommended types
Model: ZCAT2035-0930 (TDK) OP-31973 (Keyence)
DANGER Failure to follow these instructions may lead to death or
serious injury.
WARNING Failure to follow these instructions may lead to injury.
CAUTION Failure to follow these instructions may lead to product
damage (product malfunction, etc.).
Note Provides additional information on proper operation.
TIPS Indicates useful information or information that aids
understanding of text descriptions.
For Safely Using the Product
CAUTION
• Do not use the N-UB in an environment subject to flammable, explosive, or corrosive gases. • Be sure that all screws are tightened securely.
• Use crimp contacts of the specified size for wiring.
• The N-UB uses a 24 VDC power supply. Using a power
supply outside this range or an AC power supply may
cause product failure. • Do not disassemble or modify the N-UB.This may cause product failure.
96M00272
CAUTION
• Locate the cables as far as possible from high-voltage lines and power lines. Otherwise, generated noise may
cause product failure or malfunctions.
• The N-UB is a precision instrument. If the unit is dropped or shock is applied, it may be damaged. Use
caution when unpacking, carrying, and mounting.
• Be sure to observe all warnings, cautions, and precautions specified in the manual.
Foreign Regulations and Standards
Package Contents List
1 EN-UB-IM
Dedicated Communication Unit
USB Output Type Instruction Manual
General precautions
• At startup and during operation, be sure to check that the
functions and performance of the N-UB is operating properly.
• We recommend that you take substantial safety measures to
avoid any damage in the event a problem occurs.
• If the N-UB is used in any way other than described in the
specifications or if modified, its functions and performance cannot
be guaranteed.
• When the N-UB is used in combination with other instruments,
functions and performance may be degraded, depending on the
operating conditions and the surrounding environment.
• Do not use the N-UB for the purpose of protecting the human
body.
• The information contained in this manual is subject to change
without notice. Notice
When the product is used under the circumstances or environment
below, adhere to the limitations of the ratings and functions, take
countermeasures for safety precautions such as fail-safe installations
and consult a KEYENCE sales representative.
• For use under circumstances or environments which are not
described in the manual
• For use with nuclear power control, railway, aircraft, vehicles,
incinerators, medical equipment, entertainment equipment, safety
devices etc.
• For use for applications where death or serious property damage
is possible and extensive safety precautions are required For properly using the product
Do not install the N-UB in the following locations:
• Locations subject to direct sunlight
• Locations where the ambient temperature is outside the range of
0to +50 °C or locations subject to condensation as the result of severe changes in temperature
• Locations where the ambient humidity is outside the range of 35
to 85%RH.
• Locations subject to corrosive or flammable gases
• Locations subject to dust, salts, iron dust, or oil smoke
• Locations subject to shock or vibration
• Locations subject to exposure of water, oil, or chemicals
• Locations where strong magnetic or electric fields are generated UL approval
The N-UB conforms to the following UL/CSA standards and has obtained
the UL/C-UL approval.
• Conforming standard UL508, UL60950-1 • UL File No. E207185, E167973 • UL category NRAQ/NRAQ7, NWGQ2/NWGQ8 When using the N-UB as a UL approved product, be sure to observe the
following installation and environment conditions.
• Pollution degree 2
• Overvoltage category I FCC regulations
The N-UB conforms to the following FCC EMI regulations.
• Conforming regulations FCC Part 15 Subpart B, Class B
digital equipment Canada IC (Industry Canada regulations)
The N-UB conforms to the following IC EMI regulations.
• Conforming regulations ICES-003, Class B Digital equipment CE marking
The N-UB conforms to the following essential requirements of the EU
directive.
• EMC directive (2004/108/EC) By checking the conformity to the following EN standards, the conformity
to the essential requirements of the EMC directive is checked and the CE
marking is indicated.
• Conforming standards (EMI) EN55011, Class A EN55022, Class B • Conforming standards (EMS) EN61000-6-2 EN61000-6-1 * The length of the communication and power cables should be
less than 30 m.
* To make the N-UP conform to the CE marking, attach the
ferrite core to the USB cable as shown in the following
diagram. Recommended types
Model: ZCAT2035-0930 (TDK)
OP-31973 (Keyence)
DANGER Failure to follow these instructions may lead to death or
serious injury. WARNING Failure to follow these instructions may lead to injury. CAUTION Failure to follow these instructions may lead to product
damage (product malfunction, etc.). Note Provides additional information on proper operation. TIPS Indicates useful information or information that aids
understanding of text descriptions. For Safely Using the Product
CAUTION • Do not use the N-UB in an environment subject to
flammable, explosive, or corrosive gases.
• Be sure that all screws are tightened securely.
• Use crimp contacts of the specified size for wiring.
• The N-UB uses a 24 VDC power supply. Using a power
supply outside this range or an AC power supply may
cause product failure.
• Do not disassemble or modify the N-UB.This may cause
product failure.
96M00272 CAUTION • Locate the cables as far as possible from high-voltage
lines and power lines. Otherwise, generated noise may
cause product failure or malfunctions. • The N-UB is a precision instrument. If the unit is
dropped or shock is applied, it may be damaged. Use
caution when unpacking, carrying, and mounting. • Be sure to observe all warnings, cautions, and
precautions specified in the manual. Foreign Regulations and Standards
Package Contents List Main unit Instruction manual
Main unit Instruction manual
