EN-36

5000 Series Indicators

3.10.2 Baud

Set the Baud rate.
300 = 300 bps
600 = 600 bps
1200 =1200 bps
2400 = 2400 bps
4800 = 4800 bps
9600 = 9600 bps
19200

= 19200 bps

3.10.3 Parity

Set the data bits and parity.
7 EVEN = 7 data bits, even parity.
7 Odd = 7 data bits, odd parity.
7 NONE = 7 data bits, no parity.
8 NONE = 8 data bits, no parity.

3.10.4 Stop Bit

Set the number of stop bits.
1 = 1 stop bit.
2 = 2 stop bits.

3.10.5 Handshake

Set the flow control method.
NONE = no handshaking.
ON-OFF = XON/XOFF software handshaking.
HArd

= hardware handshaking.

3.10.6 Address

Set the communication address.

NOTE: Address is only displayed in the COM2 menu if the RS422/RS485 option is installed.
OFF = no address.
01 to 99 = address 01 to 99

•
