Hardy HI 1769-FC User Manual
Page 48
43
●
●
●
●
●
Chapter 4
Word
Offset
Description
RATESETPOINT
11
Total . (MSW)
STATE
12
State
VERSION
13
Firmware version
STATUS
14
Statusword (See Statusword below)
COUNTER
15
Statusword
At word 14, the module returns a binary statusword where each bit indicates a state or
condition within the module. To interpret these states, note which bits are ON and use the
chart below to match each bit location to the state it represents.
For Example: If the statusword is 69 (45 hex) with a binary value of 0000 0000 0100
0101, bits 0, 2, and 6 are on. Bit 0 indicates an A/D conversion error, bit 2 indicates
status is ON and bit 6 indicates a shutdown error.
STATUSWORD bit positions refer to these variables:
Word
#
Definition
ERRORADCONVERT 0x0001/0
Millivolt return from the load cell
system is out of range for the unit.
ERRORADFAILURE
0x0002/1
Unit’s A/D converter not responding.
STATUS_ON
0x0004/2
System on or off
ERRORLOWALARM 0x0008/3
Low
alarm
ERRORHIGHALARM 0x0010/4
High
alarm
ERRORCONTROL_LOST
0x0020/5
Controller communication failure
ERROR_SHUTDOWN 0x0040/6
Shutdown
ERROR_RANGE
0x0080/7
Out of range value
ERROR_REC
0x0100/8
REC value over high limit
ERROR_RECMINUS
0x0200/9
REC value below low limit
ERROR_REFILL_OVER
0x0400/10
Exceed refill limit
STATUS_REFILL 0x0800/11
Refill
process
active
STATUS_BATCH_COMPLETE 0x1000/12
Batch
process
completed
ERROREEPROMWRITE 0x4000/14 EEPROM
Hardware
Error
STATUSCHANENABLED
0x8000/15
Set if channel is enabled
States (Word 12 of input table)
Mode (state) Table
Mode
Value
IDLE_MODE 0
AUTO_MODE 1
MANUAL_MODE 2
START_MODE 3
STOP_MODE 4
SHUT_OFFMODE 5
PAUSE_MODE
6
