4 Hangar 9 3.1m Sukhoi SU-26MM ARF Assembly Manual
Replacement Parts
1. HAN106001 Fuselage w/ Hatch, 3.1m Sukhoi MM ARF
2. HAN106002 Hatch w/ Canopy, 3.1m Sukhoi MM ARF
3. HAN106003 Left Wing Panel, 3.1m Sukhoi MM ARF
4. HAN106004 Right Wing Panel, 3.1m Sukhoi MM ARF
5. HAN106005 Cowl (2 piece), 3.1m Sukhou MM ARF
6. HAN106006 Left Stab Panel, 3,1m Sukhoi MM ARF
7. HAN106007 Right Stab Panel, 3.1m SukhoiMM ARF
8. HAN106008 Rudder, 3.1m Sukhoi MM ARF
9. HAN106009 Carbon Wing Tube, 3.1m Sukhoi MM ARF
10. HAN106010 Carbon Stab Tube, 3.1m Sukhoi MM ARF
11. HAN106011 Landing Gear, 3.1m Sukhoi MM ARF
12. HAN106012 Linkage Hdwr Set, 3.1m Sukhoi MM ARF Replacement Parts
13. HAN106013 Wheel Pant Set, 3.1m Sukhoi MM ARF
14. HAN106014 Painted Pilot, 3.1m Sukhoi MM ARF
15. HAN106015 Main Wheel Set, 3.1m Sukhoi MM ARF
16. HAN106016 Main Axle Set, 3.1m Sukhoi MM ARF
17. HAN106017 Tail Wheel Assy, 3.1m Sukhoi MM ARF
18. HAN106018 55oz Gas Tank, 3.1m Sukhoi MM ARF
19. HAN106019 Exhaust/Batt Mnt, 3.1m Sukhoi MM ARF
20. HAN106020 Cowl/Cnpy screws, 3.1m Sukhoi MM ARF
21. HAN106021 Decal Set
22. HAN106022 Wing Bolts (6), 3.1m SukhoiMM ARF
23. HAN106023 Fiberglass Control Horn Set
Contents of kit and Parts Number
Safety Precautions and Warnings
Read and follow all instructions and safety precautions
before use. Improper use can result in fire, serious injury
and damage to property.
COMPONENTS
Use only with compatible components. Should any
compatibility questions exist please refer to the product
instructions, the component instructions or contact Horizon
Hobby, Inc.
FLIGHT
Fly only in open areas to ensure safety. It is recommended
flying be done at AMA (Academy of Model Aeronautics)
approved flying sites.
PROPELLER
Keep loose items that can get entangled in the propeller
away from the prop, including loose clothing, neck strap or
other objects such as pencils and screwdrivers. Especially
keep your hands away from the propeller as sever injury can
occur. Using a thick glove is highly recommended.
bATTERIES
Notes on Lithium Polymer Batteries
When misused Lithium Polymer batteries are significantly
more volatile than alkaline or Ni-Cd/Ni-MH batteries used
in RC applications. Always follow the manufacturer’s
instructions when using and disposing of any batteries.
Mishandling of Li-Po batteries can result in fire and rupture
causing serious injury and damage.
SMALL PARTS
This kit includes small parts and should not be left
unattended near children as choking and serious injury could
result.
Age Recommendation:
For advanced fliers ages 14 and above. This is not a toy.
