2 Hangar 9 3.1m Sukhoi SU-26MM ARF Assembly Manual 2
Intro
Intrigued by the challenge of creating model of the famed
full-scale SU-26 Sukhoi that would hold its own against the
best of scale acrobatic monoplane designs, Mike McConville
stepped up and designed this masterpiece that has exceeded
even his highest expectations. The 3.1m wingspan SU-26MM
Sukhoi is a no-holds-barred IMAC and 3D/freestyle machine
that has already proven itself at the highest levels of IMAC
competition.
Finished in Mike’s new signature trim scheme for maximum
visibility, top to bottom contrast and overall great looks,
the 3.1m SU-26MM Sukhoi will deliver best of class
performance for any serious pilot wanting uncompromised
precision. Having meticulously designed the model to
eliminate all roll and virtually all pitch coupling this the
Sukhoi has arrow-like tracking that will let you concentrate
on perfecting the maneuver at hand without the need to
worry about correcting for any unwanted tendencies in the
model.
All guess work had been taken out of this ARF, most
popular choices for engine, exhaust system and even servo
arrangements are covered in the manual. The Hangar 9 3.1m
SU-26MM Sukhoi is the ultimate in giant scale acrobatic
performance, solid construction, great looks and optimized
visual presentation in the air. Enjoy your new Sukhoi and
start turning heads at the flying field.
Product Support
For technical assistance with this product, please contact the
appropriate Horizon Product Support office.
Specifications
Wingspan 122 in (3.1m)
Length 116 in (3m)
Wing Area 2770 sq in (179 sq dm)
Weight 38–42 lb (17.2–19.2 kg)
Radio 4-channel (or greater) with 9–13
servos
Engine 150cc - 170cc gas engine
become familiar with the features of the product before
operating. Failure to operate the product correctly can result
in damage to the product, personal property and cause
serious injury.
This is a sophisticated hobby product and NOT a toy. It must
be operated with caution and common sense and requires
some basic mechanical ability. Failure to operate this Product
in a safe and responsible manner could result in injury or
damage to the product or other property. This product is not
intended for use by children without direct adult supervision.
Do not attempt disassembly, use with incompatible
components or augment product in any way without the
approval of Horizon Hobby, Inc. This manual contains
instructions for safety, operation and maintenance. It is
essential to read and follow all the instructions and warnings
in the manual, prior to assembly, setup or use, in order to
operate correctly and avoid damage or serious injury.
Table of Contents
Intro ................................................................................. 2
Product Support .............................................................. 2
Specifications ................................................................... 2
Included Parts ................................................................. 3
Contents of Kit and Parts Number .................................... 4
Safety Precautions and Warnings .................................... 4
3.1m Sukhoi Operating Recommendations ...................... 5
Important Information Regarding Warranty ..................... 5
Using the Manual ............................................................. 5
Aileron Servos Installation ............................................... 7
Elevator Servo Installation ............................................. 11
Rudder Installation ......................................................... 13
Rudder Servos Installation ............................................. 14
Main Gear and Tail Gear Installation ............................... 15
Pipes/Canisters Mount Installation and Assembly ......... 18
Cowl Mounting ............................................................... 22
Engine, Throttle Servo and DA Muffler Installation ........ 24
Fuel Tank, Fill and Over Flow Installation ........................ 25
Ignition Module, Battery,
Regulator and Switch Installation .............................. 27
Receiver Mount and
Throttle Servo Regulator Installation ......................... 29
Receiver Battery Installation .......................................... 30
Satellite Receiver and Receiver Switch Installation ........ 31
Pilot/Panel Assembly and Installation ............................ 32
Center of Gravity ............................................................ 33
Applying Decals ............................................................. 34
Control Throws .............................................................. 36
Pro-Tips ......................................................................... 36
Preflight ......................................................................... 37
Range Test Your Radio ................................................... 37
Safety Do’s and Don’ts for Pilots .................................... 37
Daily Flight Checks ......................................................... 37
Warranty and Repair Policy ............................................ 38
Warranty Services .......................................................... 38
Compliance Information for the European Union ........... 39
2010 Official Academy of
Model Aeronautics Safety Code ................................. 40
Notice
All instructions, warranties and other collateral
documents are subject to change at the sole discretion
of Horizon Hobby, Inc. For up-to-date product
literature, visit http://www.horizonhobby.com and click
on the support tab for this product.
Meaning of Special Language
The following terms are used throughout the product
literature to indicate various levels of potential harm
when operating this product:
NOTICE : Procedures, which if not properly followed, create
a possibility of physical property damage AND a little or no
possibility of injury.
CAUTION : Procedures, which if not properly followed,
create the probability of physical property damage AND a
possibility of serious injury.
WARNING : Procedures, which if not properly followed,
create the probability of property damage, collateral damage,
and serious injury OR create a high probability of superficial
injury.
WARNING: Read the ENTIRE instruction manual to
