Doepfer DIY Synth do-it-yourself analog synthesizer User Manual
Page 9
User's Guide
page 9
DIY Synth Kit
P2
VCO frequency offset
P2
VCO frequency scale
pin header JP2
(see detailed table)
pin header JP3
(see detailed table)
pin header JP4
(see detailed table)
pin header JP5
(see detailed table)
pin header JP6
(see detailed table)
pin header JP7
(see detailed table)
pin header JP1
(power supply)
-12V GND +12V
-12V
+12V
-5V
+5V
GND
GND
pin header JP10
(Tempco option)
