Capture pictures – COP-USA USBDVR04SP User Manual
Page 68

MAXDVR & DR
Series
Cards
68
Fig6.12 Delete recorded files
Users first select the channel on the left side, and then select start
time/date and end time/date of the record files, click ‘Start’ to delete files.
Capture Pictures
The definitions of the function buttons are as below:
: Capture picture
: Print setup
: Print captured picture
Notice:
Only in one channel playback pause mode (refer to Fig6.1) this
function is valid.
When in single channel playback pause mode, automatically the
following color control panel (Fig6.12) will appear, by which user can make
