MAXDVR & DR Series Cards 32
[Sensor Record Frame Rate]: If sensors are utilized to trigger recording,
users can select record frame rate here.
[Camera Security]: The users are divided into three standards: Normal
user, Power user and Administrator. By selecting the options, only
administrators can see the corresponding channels.
[Record Quality]: Select record image quality here.
[ Audio In]: MAXDVR 4.3 system can support one channel of
microphone audio input signal on the PC motherboard and audio inputs
on the card if it has. Users can choose one video channel associate these
audio signals.
Note:
Users can select more than one record mode.
Record Status Panel
Fig3.6 Record Status Panel and Alarm Output Status Panel
Meanings of indicator light colors in row one are as below:
(1) Normal State
(2) Manual Record State
(3) Schedule Record State
(4) Motion Detection Record State
(5) Sensor Alarm Record State
