COP-USA AS20RS485 User Manual
Indoor / outdoor pan/tilt system
Indoor / Outdoor Pan/Tilt System
I
．Features:
z Compact and attractive appearance, Indoor / Outdoor design
；
z Motor running stably
；
z Flame-retarded ABS material
；
z Adjustable horizontal limit switcher, the unit capable of operation with load to 6Kg
；
z RS485 data communication
；
z With internal decoder, Multi-protocol, baud rate for selectable
；
z Pan speed: 5°/sec
； Tilt speed: 5°/sec；
z With line scanning function
；
II
．Description of the Dip-switcher setting:
１．Dip-switcher
ON DI P
1 2 3 4 5 6
ON DI P
1 2 3 4 5 6 7 8 9 10
SW2
SW1
6-Dip switcher: 1 – 4 for Protocol, 5 – 6 for Baud rate
；
10-Dip switcher(frontal 9-DIP) is for the address setup:1
～511, count it as the binary system.
2
．The setting of the protocol and the default baud rate:
Protocols
Selection of Protocols
Normal Baud Rate
DIP-1 DIP-2 DIP-3 DIP-4 DIP-5 DIP-6
SAMSUNG
ON
OFF
OFF
OFF
OFF
ON
B01
ON
OFF
OFF
OFF
OFF
ON
PELCO-D
ON
ON
OFF
OFF
OFF
OFF
PELCO-P/4800
OFF
OFF
ON
OFF
ON
OFF
PELCO-P/9600
OFF
ON
Longcomity
OFF
ON
ON
OFF
OFF
ON
HUNDA600
ON
ON
ON
OFF
OFF
ON
LILIN
OFF
OFF
OFF
ON
OFF
ON
