22
Power Connector: DC12V
Red: RS485A
Yellow: RS485B
Operation Instructions
1) Main Functions Fast Call Up
Our IR Speed dome supports 220 preset positions. You can activate some special
functions by calling upon code number 65‐99.
Serial
No.
Command Fast Call Up Note
1 Start Auto Scan Call 99
Default to start auto scan of
group No.1
2 Start Auto Cruise Call 98
Default to start auto cruise of
group No.1
3 Start Pattern Tour Call 97
Default to start pattern tour of
group No.1
4
Start Auto Scan of
Group No.
Call 80+ Call pp+ Call 99
pp means：Group No.1‐8
5
Start Auto Cruise of
Group No.
Call 80+ Call pp+ Call 98
6
Start Pattern Tour of
Group No.
Call 80+ Call pp+ Call 97 pp means：Group No.1‐4
7
Stop Auto Mode/End up
Setting
Call 96
8 Open OSD Menu Set 95（or Call 95）
9 Remote Reset Call 94
10 Recover Factory Default Call 82
2) System Self‐Testing
The dome will do self‐testing after power up, and system status will show
“Normal” if system Is running normally. If error happens, testing result will be
shown in “
○ ” or “ X ”. “ ○ ” means normal and “ X ” means error. Please check the
according meaning as follows:
