19
SW1— Dip switch for the dome address
SW2— Dip switch for the dome protocol
1) Protocol Setup
Our IR speed dome supports three protocols including Pelco P, Pelco D and HS.
All of them supports baud rate of 9600bps、4800bps、2400bps.
Set the No.1~4 dip switch for the protocol configuration.
Protocol SW2‐1 SW2‐2 SW2‐3 SW2‐4
HS OFF OFF OFF OFF
PELCO P ON OFF OFF OFF
