PELCO D OFF ON OFF OFF
Reserved … … … …
2) Baud Rate Setup
Set the No.5~6 dip switch for the baud rate configuration.
3) Dome Address Setup
PELCO‐P & PELCO‐D Protocol
Add SW‐1 SW1‐2 SW1‐3 SW1‐4 SW1‐5 SW1‐6 SW1‐7 SW1‐8
1 1 0 0 0 0 0 0 0
2 0 1 0 0 0 0 0 0
3 1 1 0 0 0 0 0 0
4 0 0 1 0 0 0 0 0
5 1 0 1 0 0 0 0 0
6 0 1 1 0 0 0 0 0
7 1 1 1 0 0 0 0 0
8 0 0 0 1 0 0 0 0
9 1 0 0 1 0 0 0 0
10 0 1 0 1 0 0 0 0
11 1 1 0 1 0 0 0 0
Baud Rate SW2‐5 SW2‐6
9600 OFF OFF
4800 ON OFF
2400 OFF ON
Reserved … …
