•MOTION DETECT
The user can set up 8 motion detection scenes (each scene
with 4 detecting areas) under this menu. The alarm output will
be triggered when moving objects enter these detecting areas
SCENE NO.:
Move the cursor here and press IRIS OPEN to enter the
setup of Scene Number. Move the joystick to select a preset number (1-8)
and press IRIS OPEN to confirm.
Move the cursor here and press IRIS OPEN to enter.
Move the dome to a user-defined detecting scene. Press IRIS OPEN to
confirm.
Move the cursor here and press IRIS OPEN to enter the
menu of AREA EDIT.
a)
AREA NO.:
Move the cursor here and press IRIS OPEN to enter
the setup of AREA Number. Move the joystick to select a preset
number (1-4) and press IRIS OPEN to confirm.
b)
:
Move the cursor here and press IRIS OPEN to
enter the setup of AREA EDIT. The screen will display frame with
Serial No. The user can move the frame to the top left conner of
the wanted detecting area and press IRIS OPEN to confirm. Then
move the joystick to adjust the size of the detecting area and
press IRIS OPEN to confirm
c)
DELETE:
Move the cursor here and press IRIS OPEN to delete the
current detecting area.
d)
SENSITIVITY:
Move the cursor here and press IRIS OPEN to
enter. Select among LOW. MID and HIGH and press IRIS OPEN to
confirm the sensitivity.
e)
DELETE SCENE:
Move the cursor here and press IRIS OPEN to
delete the current scene.
f)
AUX ACTIVATE:
The dome can activate the alarm aux output
when detecting the moving object. Press IRIS OPEN to enter and
select between “ON” and “OFF” to activate or deactivate this
function.
g)
CANCEL (SEC):
Here means when the alarm aux output is
activated by the detecting function, for how long it will last before
the aux output will be closed. The time ranging 1-60 Sec.
h)
START:
Move the cursor here and press IRIS OPEN to start the
function of motion detection.
AREA EDIT
AREA NO. :1
DELETE
SEN SITIVITY :MID
AREA DISPLAY :OFF
BACK
EDIT
MAIN MENU
LANGUAGE :ENGLISH
RESTART
FACTORY DEFAULTS
HELP
EXIT
MOTION
BACK
EXIT
MOTION DETECT
SCENE NO. : 1
AUX ACTIVATE :OFF
CANCEL(SEC) :5
BACK
EXIT
