IR Speed Dome Operating Manual
28
•SOFT LIMIT
The user can set up the soft limit to define the left and
right boundaries for the pan movement.
SOFT LIMIT : Move the cursor here and press IRIS OPEN to enter.
Move the joystick to select “ON” or “OFF” to enable or disable this
function.
LEFT LIMIT: Move the cursor here and press IRIS OPEN to enter.
Now the user can mover the joystick to control the PAN movement of
the dome to a defined position for the left limit. Press IRIS OPEN to
confirm.
RIGHT LIMIT: Move the cursor here and press IRIS OPEN to enter.
Now the user can mover the joystick to control the PAN movement of
the dome to a defined position for the right limit. Press IRIS OPEN to
confirm.
LIMIT DELETE: Move the cursor here and press IRIS OPEN to
delete all the settings.
ADVANCED
BACK EXIT
MAIN MENU
LANGUAGE :ENGLISH
RESTART
FACTORY DEFAULTS
HELP
EXIT
DOME SETTINGS
BACK EXIT
LIMIT SETTING
SOFT LIMIT :OFF
LIMIT DELETE
BACK EXIT
