IR Speed Dome Operating Manual
26
•SOFT ADDRESS SET
The use can set up the SOFT ADDRESS, SOFT PROTOCOL and
SOFT BAUD RATE under this menu here to activate the soft address
function. And then the defined dome address by dip switch will be
disabled.
1) Move the cursor to INPUT (under DOME ID) and press IRIS OPEN to enter
the mode of setting dome ID, Move the joystick to position the cursor
beside :0 1 2 3 4 5 6 7 8 9” and press IRIS OPEN to enter. And move the
joystick again to select numbers of dome ID and press IRIS OPEN to confirm.
The number selected will be input on the upper line.
2) Move the cursor to INPUT (the bottom menu) and press IRIS OPEN to enter
the mode of setting soft address, Move the joystick to position the cursor
beside :0 1 2 3 4 5 6 7 8 9” and press IRIS OPEN to enter. And move the
joystick again to select numbers of dome soft address and press IRIS OPEN
to confirm. The number selected will be input on the upper line.
3) Enable or disable the soft address function. Press IRIS CLOSE to exit last
step. Move the cursor to to “SOFT ADDRESS:ON/OFF”. Press iris open to
enter. Move the joystick up or down to select ON of OFF. Press IRIS OPEN
to confirm.
4) Press OK to save and confirm all the settings and press CANCEL to exit all
the settings.
DOME SETTINGS
BACK EXIT
ADVANCED
BACK EXIT
SOFT SETTING
SOFT PROTOCOL :OFF
SOFT BAUD RETE :OFF
BACK EXIT
DOME SOFT ADDRESS SET
SOFT ADDRESS :001
INPUT ID :(000-255)
INPUT :
________
0 1 2 3 4 5 6 7 8 9
SOFT ADDRESS :OFF
OK CANCEL
MAIN MENU
LANGUAGE :ENGLISH
RESTART
FACTORY DEFAULTS
HELP
EXIT
