Page 49 IP CAMERA USER MUANUAL
9 Specification
Model 2Mega Pixel Water-Proof IP Camera
Image Sensor 1/3”CMOS
Video Compression H.264
Audio Compression G711A
Image resolution 1080P, 720P, VGA, QVGA
Shutter 1/25s~1/100000s
Low illumination 0 Lux (IR ON)
Lens 4mm, 6mm/8mm (optional)
Resolution
1920x1080(1080P)；1280x720(720P), 640x780(VGA), 320x240
(QVGA)
Stream
1080P: 512bps～8192kbps (1~30fps)
720P: 256bps～4096kbps (1~30fps)
VGA: 128bps～2048kbps (1~30fps)
QVGA: 64kbps～1024kbps(1~30fps)
Audio MIC IN*1
Network Protocol TCP/IP, DHCP, PPPoE, DDNS, SMTP, UPnP，RTSP,NTP
IR Range 10~20m No
Protection Grade IP66
Network Port RJ45
Remote Surveillance IE Browse、CMS remote control
Client Number Max 4
Power Supply DC12V/PoE(optional)
Working
Environment
-10°C ~50°C, 10%~90% humidity
