COP-USA CD55HD-IP - Manual (Page 32)

Page 26 IP CAMERA USER MUANUAL
5.5.3 Security Configuration
Enter into Advanced ConfigurationSecurity Configuration to see a tab shown in Fig
5-25:
Check “Enable IP address” check box, select “Deny the following IP address”, input IP
address in the IP address list box and click “Add” button. Then this IP address will
display in the list box; the operation step of “Allow the following IP address” is the
same with “Deny the following IP address”
Select the IP address which needs to be deleted from the IP address list box and click
“delete” button to delete that IP address.
Check “Enable MAC address” check box, select “Deny the following IP address”, input
MAC address in the MAC address list box and click “Add” button. Then this MAC
address will display in the list box; the operation step of “Allow the following MAC
address” is the same with “Deny the following IP address”.
4. Select the MAC address which needs to be deleted from the MAC address list box
and click “delete” button to delete that MAC address.
5. Click "save" button to save the above setting.
Fig 5-25 Security Configuration
5.5.4 Configure Backup & Restore
Enter into Advanced configurationConfigure Backup & Restore Interface. Refer to
Fig 5-26.

Import & Export Configuration:
User can import or export the setting information from PC or to device.
1. Click “Browse” to select save path for import or export information on PC.
2. User can import or export all setting information to PC, but those two settings “user
configuration” and “network configuration” are exceptional.
