COP-USA CD55HD-IP - Manual (Page 30)

Page 24 IP CAMERA USER MUANUAL
Fig 5-20 Add
5.5 Advanced Configuration
Advanced configuration includes five submenus: User Configuration, Onvif
Configuration, Security Configuration, Configure Backup & Restore, Reboot and
Upgrade.
5.5.1 User Configuration
Enter into "User Configuration" interface. Refer to Fig 5-21:
Add user:
1. Clicking "Add" button pops up "Add user" dialog box. Please refer to Fig 5-22:
Fig 5-21 User Configuration Fig 5-22 Add User
Note: After bind physical address to the IP-CAM, user can access the device on this PC
in network only. If the MAC address was ““00:00:00:00:00:00” which means it can be
connected to any computers.
2. Input user name in "User Name" textbox (only letters).
3. Input characters in "Password" and "Confirm Password" textbox (letters or numbers).
4. Input the MAC address of the PC in "Binding MAC address" textbox.
5. Click “OK” button and then the new added user will display in the user list.
Modify user:
1. Select the user which needs to modify password and physical address in the user
configuration list box.
2. Clicking “Modify” button will pop up “Modify user” dialog box as shown below.
Parameter Meaning
Server name The name of the FTP server
Server address The address of the FTP server
Port The port number of the FTP server
User name The user name of the FTP server
Password The password of the FTP server
Path The save path for FTP files
