Page 8 IP CAMERA USER MUANUAL
4 Remote Preview
4.1 The Remote Preview Interface
Fig 4-1 Remote Preview
 When motion detection alarm is triggered, the people icon turns red.
 Click icon to zoom in the preview image to suitable size. Drag the cursor on
the enlarged image to view suitable preview area. Click icon to zoom out the
enlarged image. Click icon to full-screen the live image.
 Clicking icon will appear a save path window and the record file can save on
your PC.
Note: On Window 7 and Window Vista, user can not record or snap pictures until UAC
function is disabled. Please refer to following steps: Start—Control panel—User
accounts—Change user account control settings in which user needs to drag the scale to
Always notify end and then click “OK” button to save.
4.2 Record Playback
Click icon and refer to Fig 4-2:
1 People icon 2 Fix size 3 Zoom in
4 Zoom in 5 Zoom out 6 Full screen
7 Start record 8 Playback 9 Snap
10 Enable audio
