Page 27 IP CAMERA USER MUANUAL
Fig 5-26 Backup and Restore Configuration

Default Configuration
Click “Load default” button to restore all system settings to default status.
5.5.5 Reboot Device
Enter into Advanced configuration—Reboot device to see the interface as shown in Fig
5-27:
Click “Reboot device” button to reboot the device.
Fig 5-27 Reboot device interface
5.5.6 Upgrade
Enter into Advanced Configuration—Upgrade interface as shown in Fig 5-28:
1. Click “Browse” button to select the save path of the upgrade file
2. Click “Upgrade server firmware” button to start upgrading the application program
3. The device will restart automatically
4. After you successfully update the software, click “OK” button to close IE and then
re-open IE to connect IP-Cam.
Fig 5-28 Upgrade
Notice: User can‟t disconnect to PC or close the IP-CAM during upgrade.
