7.0 RECALLING TENSION VALUES STORED IN MEMORY

Using the Tension Inspect software, you can easily and accurately evaluate the stored
tension values and export them to an Excel spreadsheet.

7.1 Recalling Stored Values in Mode S (Standard)

1. Turn on the tension meter and press the RECALL key, You can exit

recall at any time by pressing the POWER key.

Memory Mode STANDARD

Pos:

1 Pos:

2 Pos:

3 Pos:

AVG:

22.0 AVG:

12.0 AVG:

12.0

Last:

23.0 Last:

22.1 Last:

22.1

MAX:

24.0 MAX:

22.1 MAX:

22.1

MIN:

21.0 MIN:

5.4 MIN:

5.4

PEAK

MAX

26.0 PEAK

MAX

28.1 PEAK

MAX

28.1 PEAK

MAX

28.1

PEAK

MIN

19.0 PEAK

MIN

1.8 PEAK

MIN

1.8 PEAK

MIN

1.8

2. The DISPLAY blinks showing the average value (AVG)

of the first measuring period (POS: 1) and the
symbol.

3. Press the RECALL key. The DISPLAY blinks, showing

the last value (LAST) of the measuring period.

4. Press the RECALL key. The DISPLAY blinks, showing

the maximum value (MAX) or the measuring period
and the symbol.

5. Press the RECALL key. The DISPLAY blinks, showing

the minimum value (MAX) of the measuring period
and the

symbol.

6. Press the RECALL key. The DISPLAY blinks, showing the

maximum peak value (PEAKMAX) of the measuring period
and the

symbol.

7. Press the RECALL key. The DISPLAY blinks, showing the

minimum peak value (PEAKMIN ) of the measuring period,
the PEAK indicator and the

symbol.

8. Press the RECALL key. The next measuring period (POS: 2) is shown on the

DISPLAY, starting with the average value (AVG).

Peak cN

– 23 –

9.3 Restoring Factory Calibration

You can restore the factory calibration at any time with the following procedure:

1. Switch off the tension meter.

2. Press and hold the MEM and POWER keys until the DISPLAY shows E-0 cN .

3. Release first the POWER key and then the MEM key.

4. Press and hold the DAMP and RECALL keys, then additionally

press and hold MEM until the DISPLAY shows - - - -cN .

The factory calibration is restored.

5. Release the DAMP, RECALL and MEM keys.

6. Press the POWER key. The instrument switches off.

10.0 WINDOWS TERMINAL PROGRAM

The measured values and the memory contents can be transmitted over the USB
interface to a personal computer.

For data transfer to the PC, you will need a USB driver. If no matching driver is installed
on your PC, the Windows Found New Hardware Wizard appears when you connect the
unit to the computer for the first time. Follow the wizard steps. Specify the location of
the driver on the supplied CD-ROM. You will find the driver in the “Treiber” folder.

You can connect the computer to the INTERFACE of the ETX by using the EK-0662
special cable which is included in delivery.

Requirements:

A communication program, such as Terminal or HyperTerminal (provided on MS
Windows Version 3.0 or later), must be installed and configured on the computer.

Commands for communication with a PC (polling)

E-0

----

ASCII

Code

Function

Description

transmission Transmission of the undamped reading.

Send

Transmit current reading to PC once.

Output

Output the memory contents to the PC.
