Brookfield Bath, Model TC-602 User Manual
Page 9
8
?!
#$0/9/0&'/(+)!!
Model
TC-102P
TC-202P
TC-502P
TC-602P
TC-900P
Temperature Range
-20° to 200°C
-20° to 150°C
-20° to 200°C
-20° to 200°C
-40° to 200°C
Cooling
Tap Water*
Tap Water*
Refrigerated
Refrigerated
Refrigerated
Reservoir Capacity
6.0 liter
10 liter
6.0 liter
6.0 liter
13.0 liter
Temperature Stability
±0.01°C
Controller / RS232
Yes
External Temperature Probe
Functional on Programmable models / optional external probe required
Readout Accuracy
Graphic LCD, °C or °F, ±0.25°C
Heater
1100W – 115V, 2200W – 240V
Pressure Flow Rate
15.7 to 30 LPM (60Hz); 15 to 22 LPM (50Hz)
Suction Flow Rate
11 to 22 (60Hz); 10 to 15 LPM (50Hz)
Over-Temperature Protection
Yes, user-adjustable Safety Set Point
Low-Liquid Protection
Yes
Pump Speeds
Variable
Pump Inlet and Outlet
¼ inch FPT rear discharge. (M16, Male - 50Hz Models Only)
Dimensions in.
(l x w x h) cm
14
3
/
4
x 8
1
/
4
x 14
37.5 x 13.3 x 35.6
13
1
/
4
x 14
1
/
4
x 13
1
/
4
33.7 x 36.2 x 33.7
15
3
/
4
x 18
3
/
4
x 17
40 x 47.6 x 43.2
15
3
/
4
x 8
1
/
4
x 22
1
/
2
40 x 21 x 57.1
17 x 15½ x 24¾
43.2 x 39.4 x 62.9
Unit Weights
22 lbs (10.0 kg)
28 lbs (12.7 kg)
63 lbs (28.6 kg)
68 lbs (30.9 kg)
145 lbs (66 kg)
Reservoir Volumes
6.0 liters
10.0 liters
6.0 liters
6.0 liters
13.0 liters
Power Requirement
11A @
115V / 1 / 60Hz
(105V - 125V)
9.8A @
240V / 1 / 50Hz
(200V - 260V)
11A @
115V / 1 / 60Hz
(105V - 125V)
9.8A @
240V / 1 / 50Hz
(200V - 260V)
12A @
115V / 1 / 60Hz
(105V - 125V)
9.9A @
240V / 1 / 50Hz
(200V - 260V)
12A @
115V / 1 / 60Hz
(105V - 125V)
9.9A @
240V / 1 / 50Hz
(200V - 260V)
14A @
115V / 1 / 60Hz
(105V - 125V)
9.9A @
240V / 1 / 50Hz
(200V - 260V)
NOTE: Performance specifications determined at ambient temperature of 20°C (68°F).
* For use at lower temperatures, use the built-in tap water cooling, or use model TC-351 Cooler for control to -20°C
Environmental Conditions:
! Indoor Use Only
! Over Voltage: Category ll
! Maximum Altitude: 2000 meters
! Operating Ambient: 5° to 30°C
! Relative Humidity: 80% for temperatures to 30°C
! Pollution Degree: 2
! Class 1: Residential, Commercial, Light Industrial
! Class 2: Heavy Industrial
