82 • • • • Technical Specifications
Physical Dimensions (nominal)
Height 3.48" [89mm] (Standard EIA Rack, 2U High)
Width 17" [432mm], except rack mounting ears at 19” [483mm]
Depth 12" [305mm]
Net Weight 12.75 Lbs [5.6 Kg]
Shipping Weight 20 Lbs [9 Kg]
Audio Configuration Specifications
Sampling Frequencies 96 kHz, 88.2 kHz, 48 kHz, 44.1 kHz
Audio Coding 24- or 16-bit Linear PCM
Audio Sync References Internal crystal, AES-3 receiver, or AES-11 sync
Input Impedance 20K ohms, each leg
Input Circuit Balanced, RF suppressed, XLR-3
Output Circuit Balanced, XLR-3
Digital Inputs/Outputs AES/EBU, XLR-3 110Ω; AES-3id-2000, BNC, 75Ω; IEC-958 Type II, BNC
(requires RCA adapter)
Sample Rate Conversion 24-bit, input or output, ratio = 3:1 maximum
Data Reduction Optional, Dolby AC-2 at 16-bit, 48K only
File Formats .WAV (16 or 24-bit); .DC2 (16 bit); .AC2
Headphones Stereo, ¼” front panel jack
Audio Performance Specifications
24-Bit Linear PCM
Signal-to-Noise, A/D 115 dB typical
Signal-to-Noise, D/A 116 dB typical
Distortion, A/D (THD+N) 0.0015% ref. to full scale
Distortion, D/A (THD+N) 0.0015% ref. to full scale
Bandwidth, 44.1K or 48K 10Hz – 21 kHz ±0.2 dB
Bandwidth, 88.2K or 96K 10 Hz – 42 kHz ±0.2 dB
Max Input Level +20 dBu
Headroom Above +4 dBu 16 dB
Max Output Level +20 dBu
Nominal Output Level +4 dBu
Interchannel Crosstalk < -100 dB 10 Hz – 20 kHz
Interchannel Phase Deviation < 0.1 degree at 15kHz
