Maintenance • • • • 65
H ANDLING AND C ARE OF Z IP D ISKS
Although the plastic shell protects the data surface from most accidental damage, the following rules MUST
be observed:
• DO remove the disk from the drive after use. Return it to its protective case to prevent
damage from dirt and spills.
• DO NOT manually open the access door on the disk drive.
• DO NOT open the disk when it is outside the drive.
• DO NOT insert objects into the disk.
• DO NOT handle the front edge of the disk. Oils can be transferred from hands to the
media surface.
• DO NOT transport the drive with the disk inserted. If the drive is to be moved with the
power off, the disk must be removed before turnoff.
• DO NOT leave a disk partially inserted in the drive. This increases the possibility of
damaging the disk or the drive.
• DO NOT put a disk near a loudspeaker, transformer, telephone or electric motor.
• DO NOT expose disks to direct sunlight or moisture.
• DO NOT expose disks to magnetic fields greater than 30 Gauss.
• DO NOT store disks at temperatures above 125º F (50º C).
Special Button Sequences
SPECIAL BUTTON SEQUENCE FUNCTIONS
Button Sequence Function
Utility+Power Switch Restore previous operating system version
Utility+Hot Key 1 Load new operating system to flash memory
Utility+Hot Key 2 Copy operating system to Zip disk. This is useful when
installing the operating system on non-networked
DigiCarts.
Utility+Hot Key 3 Not assigned
Utility+Hot Key 4 Front panel LED test. All indicators should illuminate
together for 3 seconds.
