Page 79: 1394 port
Interface Wiring •
•
•
•
69
Aux Serial Port
This port is dedicated to external third-party serial controllers using either ES-Bus or Peripheral Bus
protocols. Configure this setting in SET AUX PROTOCOL in the SETUP menu.
PIN
SIGNAL
1
GND
2
RX - (DigiCart Receiver, wire to TX-)
3
TX + (DigiCart Transmitter, wire to RX+)
4
TX GND
5
N/C
6
RX GND
7
RX + (DigiCart Receiver, wire to TX+)
8
TX - (DigiCart Transmitter, wire to RX-)
9
GND
Keyboard Port
A PS/2 style connection, any 101-Key or compatible keyboard may be connected.
PIN
SIGNAL
1
DATA
2
N/C
3
GROUND
4
+5 V
5
CLOCK
6
N/C
Network Port
This is a 100Base-T standard Ethernet port. Connection is made with an RJ-45 cable connector. Two LED
status indicators are included on the connector. The green LED lights to indicate a valid network
connection. The yellow LED lights to indicate communication activity.
This connection is intended for use only with 360 Systems’ Ethernet Audio Server system. It is not suitable
for connection on a generic LAN or WAN system.
1394 Port
This feature is not currently implemented.
