MAXX-2420-EX Owner’s Manual Page 55
Disable Network [X]
This selection turns the network OFF or ON. The default is Disabled (the box is checked). To
Enable the network connection, click the box to un-check it. Disabling the network can be used
to deny access to the server from the network for security purposes.
Enabling/Disabling DHCP [X]
Enabling DHCP will configure the network interface automatically.
If the DHCP box is not selected, the user may then manually enter assignments in the following
windows:
• IP Address ( Example: 192.168.1.20 )
• Net Mask ( Example: 255.255.255.0 )
• Default Router ( Example: 192.168.1.1 )
The Host Name and NTP domain name may be a fully qualified domain name, such as
edit1.mydomain.com. All other manually configured addresses must be properly formatted IP
addresses.
Saving Network Configuration
Click on OK, APPLY, or CANCEL to accept or abandon new entries.
The IP address of the system is displayed in the upper-left corner of the GUI at the end of the
main window title.
IMPORTANT
The server is designed to be used in a private dedicated video network. An external
firewall (preferably with Virtual Private Network (VPN) support) must be used in systems
that require internal security or connection to public networks.
Consult with a network security specialist for guidance on the best hardware, programming
and practices for your facility’s requirements.
