iMcaMon
Basic/Tuner controls
CD/Cassette deck controls
No.
®
Name
Ref. page
Band select button (BAND)
11
Standby indicator [STDBY ci) (AC)]
When the unit is connected to the AC mains supply, this indica
tor lights up in standby mode and goes out when the unit is
turned on.
Preset equalizer button (PRESET EQ)
15
@ Battery check indicator (BATT/POWER) 5
d) Power “STDBY (!) (AC)/ON” switch
(POWER)
Press to switch the unit from on to standby mode or vice versa.
In standby mode, the unit is stilt consuming a small amount of
power.
@ Speakers
@ Time set/Tuning buttons
(CD/TUNEA-IME ►►(/+, «◄/-)
Zll
Time adjust button
(CLOCK/TIMER, ADJUST)
(9) Timer button (TIMER)
@ Volume control buttons (VOLUME +, —)
21,23
8,11,13
This portable stereo can play and record with the touch of a
single button. Therefore, in order to keep from accidentally
recording over important tapes, we recommend that you
remove the recording-protection tabs from your tapes (see
page 30).
No. Name
Ref page
(0) Stop/ciear button (l/CLEAR)
8
© Play/pause button (^/11)
8
@ Disc lid
8
© Disc lid open button (A)
8
@ Skip/Search buttons
(CD/TUNEyriME ►►]/+, «◄/-)
8
© CD rec mode button
(CD REC MODE AUTOZONE)
18,19
© Tape eject button (A)
13
@ Tape play/direction button (◄ ►)
13
© Tape stop button (■)
13
@) Rec/rec pause button
(•/•II REC/PAUSE)
16,20
@ Rewind/TPS button (REW iiEi)
14
@ Fast forward/TPS button i fr^ FF)
14
