Location and function of each part
Monitor
Opening the control panel cover or the
connector panel cover.
Push the place marked “PUSH” and then
release it.
The cover will then open.
©Front connector panel
©Front control panel
1
r —r
—g' '
-©Main power switch
©Power indicator
® Front connector panel
Audio 2 Input RCA jacks
S-video 2 Input connector-
AV 2 INI ____________
S-VIDEO VIDEO i
AUDIO
L
R
f/o
p@i
®
©
RGB2 IN
iH
EZ}
15 Pin HDD-sub
Video 2 Input RCA jack
15 Pin HD D-sub:
This connector is for the 15 Pin HD D-sub end of
the signal cable for IBM or compatible
computers for mass production.
Video 2 Input RCA jack:
This jack is for composite video signal cable (not
supplied) when used with a video equipment.
S-video 2 Input connector:
This terminal is for S-video signal cable (not
supplied) when used with a video equipment
adopting S-video.
Audio 2 Input RCA jacks:
These jacks are audio inputs from a video
equipment (signal cable not supplied).
