VCR and Cassette Information
Erase Protection (Record Tab)
Cassettes have a record tab to ensure that
recordings are not accidentally erased.
To prevent accidental
erasure, break off the tab
with a screwdriver! ----------
To record again, cover the
hoie with celiophane tape.
Reset all VCR Memory Functions
Use when moving the VCR to a new location, or if a mistake
was made in the One Time VCR Setup section.
• Make sure a tape is not inserted in the VCR.
1) Turn VCR Power on.
2) Push and hold both PLAY and CHANNEL A on the VCR
for more than 5 seconds.
• The power will shut off.
3) Perform the One Time VCR Setup section on page 14.
Maximum Record/Playback Time
Only use tapes with the № mark in this unit.
Tape Speed
Setting
Type of Video Cassette
T60 T120 T160
SP
(Standard Play)
1 Hour 2 Hours
2 Hours
40 Minutes
LP
(Long Play)
2 Hours 4 Hours
5 Hours
20 Minutes
SLP
(Super Long Play)
3 Hours 6 Hours 8 Hours
Buiid-in Head Cieaner
A clean video head helps produce a clear picture.
So, we have equipped your VCR with a built-in, non
chemical head cleaning system that helps prevent
clogging of the video heads. Cleaning is performed
each time you load or unload a video cassette.
Note: This feature is preventative only. If your video
heads are seriously clogged, consider the use of
a chemical nonabrasive head cleaning kit or take
your VCR to a Service Center.
Head Cleaning
Your VCR will not normally require head cleaning,
however the heads may become clogged when playing
an old or damaged tape.
Video Heads Sensor System
If head cleaning becomes ______________________________
necessary, the VCR will
display the screen at right
while playing back a
recorded signal.
To exit this screen, push PLAY
on the remote control or VCR.
• Use “dry" type head ___________________
cleaning cassette* only.
• Be sure to follow the cleaning tape instructions
carefully. Excessive use of a cleaning cassette can
shorten head life.
• If using a head cleaning cassette does not solve the
problem, contact your nearest Factory Service Center
or authorized Service Center.
• Cleaning cassette part No. NV-TCL30PT is
recommended.
VIDEO HEADS MAY
NEED CLEANING
PLEASE INSERT HEAD
CLEANING CASSETTE
OR REFER TO MANUAL
END:PLAY KEY
D.S.T. (Daylight Saving Time)
Spring (First Sunday in April)
When the VCR is set to DST:ON, it automatically adds
one hour and adjusts thè clock.
NORMAL TIME
1:00 a.m. 2:00 a.m,
DAYLIGHT
SAVING TIME 3:00 a.m. 4:00 a.m.
Autumn (Last Sunday in October)
When the VCR is set to DST:ON, it automatically turns back
one hour and adjusts the clock.
DAYLIGHT
SAVING TIME
1:00 a.m. 2:00 a.m.
NORMAL TIME
1:00 a.m. 2:00 a.m.
Specifications
Power Source:
Power Consumption:
Video Signal:
Video Recording System:
Audio Track:
Tuner:
Broadcast Channels:
CATV Channels:
Operating Temperature:
Operating Humidity:
Weight:
Dimensions:
120V AC, 60 Hz
Approx. 23 watts (Power on)
Approx. 7 watts (Power off)
ElA Standard NTSC color
4 rotary heads helical
scanning system
1 track (Normal)
2 channel (Hi-Fi Audio Sound)
VHF2~13, UHF 14-69
Midband A through I (14-22)
Superband J through W (23-36)
Hyperband AA-EEE (37-64)
Lowband A-5-A-1 (95-99)
Special CATV channel 5A (01)
Ultraband 65-94, 100-125
4rF-104°F(5°C-40°C)
10%-75%
7.7 lbs. (3.5 kg)
16-15/16" (W) X 3-2/3" (H) X
11-13/16” (D)
430 (W) X 93 (H) X 300 (D) mm
Note: Designs and specifications are subject to change
without notice.
