Panasonic OMNIVISION VHS PV-7662 - Manual (Page 17)

To Change On Screen Display Language
MENU
SET UP VCR
SET CLOCK
SET UP CHANNEL
I: ENGLISH IDIOMA/LANGU
SELECT :A T KEY
SET > KEY
END :MENU KEY
1 Push MENU to display the menu.
2 Push AT to select
the language.
English: LANGUAGE
Spanish: IDIOMA
French: LANGUE -------------------
3 Push ► repeatedly to change the language.
I ► English-------- ► Spanish ► French —|
4 Push MENU to exit this mode.
To Add or Delete a Channel
1 Select a channel using the
NUMBERED keys to add
or CH A/T to delete.
2 PushADD/DLTtoaddor
delete the channel.
• To select a channel once it’s
deleted, use the NUMBERED
keys on the remote control.
Deleted channels will flash in the Multi
Function Display on the VCR when selected.
When Using the 100 key
When selecting CATV channels 100 to 125 with the
NUMBERED keys, first push the 100 key and then
enter the remaining two digits.
For example, to select channel 125;
Push NUMBERED keys 100, then 2, then 5.
To Replace Channels in Memory
In case you have cable installed, etc.
1 Push MENU to display the menu.
2
Push AT to select “SET UP
CHANNEL,” and then push ►
to display the “SET UP
CHANNEL” screen.
Push AT to select
“ANTENNA SYSTEM,” and
then push ► to set your
antenna system (TV or CATV).
.................... MENU .....................
SET UP VCR
SET CLOCK
щввв™
I blOMA !NGL ISH
SELECT:* ▼ KEY
SET :► KEY
:MENU KEY
--- SET UP CHANNEL —-
ANTENNA SYSTEM _ _ CATV
ALiTO SET
CABLE/DSS BOX SET UP
VCR P)iis+ CH SET UP
SELECT:* ▼ KEY
SET ;► KEY
END :MENU KEY
Push AT to select “AUTO
SET," and then push ► to
display the “CHANNEL7CLOCK AUTO SEr screen.
• To exit this mode, push MENU twice.
Follow the One Time VCR Setup
instructions on pages 14-16.
• Clock Auto Set will be performed when channels are
replaced in memory. To cancel, push STOP when
“AUTO CLOCK SET PROCEEDING” appears on-screen.
To Set or Reset the Clock
In case the clock is wrong, or a power failure occurred.
1 Push MENU to display the menu.
2 Push AT to select “SET
CLOCK,” and then push ►
to display the “SET CLOCK"
screen.
3 Push AT to select “MANUAL
SET," and then push ►
to display the SET CLOCK
screen.
4 Push AT and to select
and set the date, time, and
D.S.T. (Daylight Saving Time).
5 Push MENU twice to start the
clock and exit this mode.
MENU
SET UP VCR
SET UP CHANNEL
ID10МА/ LANGUE: ENGL 1 SH
............. SET CLOCK..................
AUTO SET
SELECT;* ▼ KEY
SET :► KEY
END :MENU KEY
............. SET CLOCl\h/--A:|-/
тчтШтщ
SELECT:* T KEY
SET :•« ► KEY
END :MENU KEY
To Set or Reset Auto Clock Set
Complete the following steps if:
• Auto clock set displayed time was incorrect.
• Auto clock set was not available at first, but has
since become available.
• The PBS channel over which clock data is sent
was changed by the broadcast company.
1 Push MENU to display the menu.
2 Push AT to select “SET
CLOCK," and then push ►
to display the “SET CLOCK”
screen.
5 Push AT and ► to select
and set “AUTO SET.”
4 Follow the One Time VCR
Setup instructions on pages
14-16.
.................... MENU
SET UP VCR
SET UP CHANNEL
IDIOMA/LANGUE: ENGLISH
............. SET CLOCK..................
MANUAL SET
SELECT:* T KEY
SET :► KEY
END rMENU KEY
To setup the VCR In case a cable box or
DSS receiver was installed or replaced
1 Push MENU to display the menu.
2 Push AT to select “SET UP
CHANNEL,” and then push ►
to display the “SET UP
CHANNEL” screen.
3 Push AT to select “AUTO
SET," and then push ► to
display the “CHANNEL/CLOCK
AUTO SET” screen.
• To exit this mode,
push MENU three times.
4 Push AT and ► to select and
set “CABLE/DSS BOX^VCR
► TV," and then continue with
steps 5-8 on pages 14 and 15.
...................... MENU
SET UP VCR
SET CLOCK
SET UP CHANNEL
ID ЮМЛ/ LANGUE: ENGL I SH
--- SET UP CHANNEL ---
ANTENNA SYSTEM : CATV
AUTO SET
wj:iiiri»^-ki=»:ggiig
VCR PIUS+ CH SET UP
SELECT:* T KEY
SET :► KEY
END :MENU KEY
SELECT HOOKUP
CABLE/DSS BOX^VCR^TV
VCR^CABLE/DSS BOXP-TV
VCR^TV
SELECT
SET
END
* T KEY
► KEY
MENU KEY
This VCR will accurately maintain its calendar up to Dec. 31,2015,11:59PM.
Normal TV or Cable channels are automatically selected and placed in memory depending on how your VCR is hooked up.
If you change your cable box or DSS receiver, please perform the “To Set or Reset Auto Clock Set" section above.
17
