li||W| MTS Broadcast/ VHS Hi-Fi Stereo System
l^c
Check list before you begin
D
The VCR is connected to a stereo TV, or a mono TV and an external stereo amp or receiver with speakers.
Q The VCR and other components are plugged in and turned on.
to either a stereo TV, or a mono sound TV
with an external stereo amp and speakers.
go
"HI ^
eoo II
— ------ -
Receivable Broadcast Types
The following are possible audio broadcast types and on-screen displays.
Parenthesis indicate signal(s) not being received. The arrow indicates the
selected audio mode.
Multi Function Display
DISPLAY
Push DISPLAY to display the broadcast
signal currently being received.
Et^R
DISPLAY
Equipped with
dbx®
-TV Noise Reduction
for true MTS reproduction.
(ibx*
-TV
Noise Reduction is required for good
stereo separation and audio fidelity,
dbx*
is a registered trademark, and is
licensed by dbx® Technology Licensing.
28
MTS Stereo and SAP broadcast
Multi-channel Television Sound Stereo
(main language) and Secondary Audio
Program (sub language) broadcasts are
being received simultaneously.
The “STEREO" and “SAP” indicators
light in the Multi Function Display.
Select STEREO or SAP audio mode.
MTS Stp.rfin broadcast
Multi-channel Television Sound Stereo
broadcast. The “STEREO” indicator
lights in the Multi Function Display.
Select STEREO audio mode. .
• If a stereo broadcast is weak and the display
flickers, you may want to select the MONO
audio mode for better results,
SAP broadcast
Secondary Audio Program (sub language)
broadcast. The “SAP" indicator lights in the
Multi Function Display. Select SAP audio
mode for the sub language.
MONO broadcast
Normal monaural sound broadcast.
STOP 12:00AM CH08
0:00:00
SPATIALIZER ON SLP
STEREO ■«
SAP
MONO
STOP 12;OOAM CH08
0:00:00
SPATIALIZER ON SLP
STEREO
A
(SAP)
MONO
STOP 12:00AM CH08
O'.OO'.OO
SPATIALIZER ON SLP
(STEREO)
SAP <
MONO
STOP 12:00AM CH08
0:00:00
SPATIALIZER ON SLP
(STEREO)
(SAP)
MONO <
