Panasonic OMNIVISION VHS PV-7662 - Manual (Page 30)

%ble Box I
ontrol
VCR Plus+ Setup
Easy Taping.
In order for the VCR to read the VCR Plus+ code, some set up is required. A Guide (VCR Plus+) channel
number is assigned to each local broadcast and cable station. Because this number sometimes differs from
the channel your TV receives the station on, it is necessary to program the VCR with local channel information.
VCR Plus+ Channel Setup
For Connection Method 2 (on page 12) only
• Before you begin, complete the Channel Setup
Preparations below left.
Important Note:
If your VCR connection method changes from 1 to 2, perform “To
setup the VCR in case a cable box or DSS receiver was installed or
replaced" section on page 17 before proceeding with these steps.
Push MENU to
display the menu.
Channel Setup Preparations
NOTE: Complete the steps on this page if you
are using Connection Method 2 on page 12 for
your VCR hookup.
Prepare a list like the example below.
This list will help you smoothly enter the
information needed in step “4" at right.
You will need the following to complete the list;
H A line up of normal and/or cable stations you
receive along with the channel numbers your
TV receives them on. A cable channel line-up
chart is supplied by your cable company.
I A list of Guide (VCR Plus+) channel numbers
assigned to the stations you receive. This list is
available in TV
Guide and the TV listings found
in selected newspapers.
1
Make a chart with 3 columns like the example
below. In the left column, fill in the name or call
letters of the stations you receive.
In the middle column, fill in each station’s
assigned Guide (VCR Plus+) number found in
TV Guide, newspapers, etc.
In the right column, fill in the channel number
that your TV receives the station on from your
channel line-up.
EXAMPLE ONLY
Broadcast or Cable
Station Name
Assigned
Guide
(VCR PIUS+)
channel no.
Channel no.
your TV
receives the
station on
HBO 33 15
Nickelodeon 38 20
CBS 04 04
FOX 11
.................. MENU ....................
SET UP VCH
SET CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGL ISH
SELECT ;A ▼ KEY
SET :► KEY
E№ :MEMU KEY
Push AT to select
“SET UP CHANNEL,"
and then push ► to display
the “SET UP CHANNEL” screen.
Push
AT
to select
“VCR Plus-h CH SET
UP," and then push ►
to display the “VCR
Plus-p CH SET UP”
screen.
--- SET UP CHANNEL ---
ANTENNA SYSTEM : CATV
AUTO SET
CABLE/DSS BOX SET UP
SELECT
SET
END
A ▼ KEY
► KEY
MENU KEY
IMPORTANT NOTE:
For step “4,” use the list you prepared. You may leave lines
blank if you don’t receive that station, or if the GUIDE CH
number and the CATV (or TV) CH numbers are the same.
Push ► to move
the shaded area to
the right side.
Then, push AT to change CATV
or TV CH number.
Next, push ^ to set the number.
Now, push AT to continue.
Repeat this operation until the list is
complete.
VCR P1US+ CH SET UP
GUIDE CH CATV CH
► 3l
02
SELECT:* ▼ KEY
SET :► KEY
END :MENU KEY
VCR PIUS+ CH SET UP
GUIDE CH CATV CH
► 0 1
02
SELECT
SET
END
A ▼ KEY
< KEY
MENU KEY
To Make Corrections
Push AT and ► to select the incorrect CATV or TV CH number,
Then, push AT to change, or ADD/DLT to delete the channel.
Push MENU three times
to exit the VCR Plus-i- CH
SET UP mode.
Make each entry within 5 minutes or the VCR will leave this mode.
Once local channels have been programmed, they will stay in
memory, even in the case of a power failure.
VCR Plus+C^ and PlusCode are trademarks of Gemstar
Development Corporation. The VCR Plus+ system is manufactured
under license from Gemstar Development Corporation.
