Main unit (continued) d
No.
Name
Ref. page
© CD rack panel........................................................................... 14
© CD rack panel open button (OPEN)............................................ 14
@ CD MANAGER button
(CD MANAGER)..................... ........................................... 20,35
0 Disc/track select button/indicator
(DISCmACK)...................................................... 15
® Text edit button (TEXT EDIT)...................................... ................ 23
® Text mode select button (TEXT MODE) ...
21
@ Jog dial (JOG)........................................................................... 15
® Headphone jack (PHONES)........................................................ 43
(9) Acoustic image equalizer display
(Al EQ) ...... ..................... -.................................................. 28
0 Sound equalizer control/indicator
(SOUND EQ)......................................................................... 27
(Jj) Deck 2 open button
(DECK 2 ^ OPEN)................................................................. 25
Remote control El
Buttons such as (p function in exactly the same way as the buttons
on the main unit,
0 Power button (POWER)............................. .. 11
@ Numeric buttons ...... ............................... ............... 16
@ Program button (PROGRAM).................. ............... 18
® Cancel button (CANCEL)..................... ............... .... 19
0 Input selection buttons
(AUX, TAPE, CD, TUNER)................. 12,15, 25, 43
SC-AK95 only
Channel select button (CH SELECT)................... 31
SC-AK95 only
DOLBY PRO LOGIC on/off button
(□□ PRO LOGIC)..................................................... 30
® Muting button (MUTING) .......................................... 37
0 ◄/v button (◄/v)........... ................................... .. 13, 25
@ Sleep button (SLEEP)............................................... 43
@ Equalizer button (EQ)............................................. 27
0 Super woofer on/off button (S. WOOFER) ... 27
@ Disc button (DISC).................................................. 18
@ Random button (RANDOM) .................................... 17
@ Repeat button (REPEAT).................. ..
17
SC-AK95 only
Channel level select buttons
(~ CH LEVEL +).................... .. . .
31
SC-AK95 only
Test button (TEST).............................................. 31
0 \«/« ►►/►w buttons
►►/►w)....................................... 15, 26
© ►/II/
a
button
(►/!!/
a
)
.................................................. 13,15,25
0 Stop button (■)...................................................... 15,25
0 Volume buttons (— VOLUME +) ............ .................. 13
